PPO FE1740PW 40%Glass Reinforced
| 產品型號： |
FE1740PW |
| 產品規格： |
PPO |
| 產品品牌： |
沙伯基礎創新（美國） |
沙伯基礎創新塑料(聚亞基醚和聚乙烯) PPE+PS、FE1740PW、ENG265、EXNL0143、EXNL0357、EZ250、FE1410PW、FE1520PW、FE1630PW、經營產品 Noryl PPO, Lexan PC, Valox PBT, Ultem PEI, Cycoloy PC/ABS, Xylex PC/PET, Xenoy PC/PBT/PET:
|
|
|
Noryl? FE1740PW resin is a blend of polyphenylene Oxide (PPO) and polystyrene (PS) resin that contains 10% glass reinforcement. The resin is suitable for injection molding. Noryl FE1740PW resin has been developed for fluid engineering applications that require improved hydrolytic stability. Noryl FE1740PW resin has been certified for potable water applications up to 85C in Europe and North America in limited colors.
|
|
|
|
TYPICAL PROPERTIES (1)
|
|
MECHANICAL
|
Value
|
Unit
|
Standard
|
|
Tensile Stress, brk, Type I, 5 mm/min
|
950
|
kgf/cm2
|
ASTM D 638
|
|
Tensile Strain, brk, Type I, 5 mm/min
|
2.8
|
%
|
ASTM D 638
|
|
Tensile Modulus, 5 mm/min
|
48600
|
kgf/cm2
|
ASTM D 638
|
|
Flexural Stress, brk, 1.3 mm/min, 50 mm span
|
1370
|
kgf/cm2
|
ASTM D 790
|
|
Flexural Modulus, 1.3 mm/min, 50 mm span
|
49500
|
kgf/cm2
|
ASTM D 790
|
|
Tensile Stress, break, 5 mm/min
|
94
|
MPa
|
ISO 527
|
|
Tensile Strain, break, 5 mm/min
|
2.7
|
%
|
ISO 527
|
|
Tensile Modulus, 1 mm/min
|
4930
|
MPa
|
ISO 527
|
|
Flexural Stress, break, 2 mm/min
|
135
|
MPa
|
ISO 178
|
|
Flexural Modulus, 2 mm/min
|
4880
|
MPa
|
ISO 178
|
|
IMPACT
|
Value
|
Unit
|
Standard
|
|
Izod Impact, unnotched, 23°C
|
23
|
cm-kgf/cm
|
ASTM D 4812
|
|
Izod Impact, unnotched, -30°C
|
22
|
cm-kgf/cm
|
ASTM D 4812
|
|
Izod Impact, notched, 23°C
|
3
|
cm-kgf/cm
|
ASTM D 256
|
|
Izod Impact, notched, -30°C
|
3
|
cm-kgf/cm
|
ASTM D 256
|
|
Izod Impact, unnotched 80*10*4 +23°C
|
13
|
kJ/m2
|
ISO 180/1U
|
|
Izod Impact, unnotched 80*10*4 -30°C
|
13
|
kJ/m2
|
ISO 180/1U
|
|
Izod Impact, notched 80*10*4 +23°C
|
4
|
kJ/m2
|
ISO 180/1A
|
|
Izod Impact, notched 80*10*4 -30°C
|
4
|
kJ/m2
|
ISO 180/1A
|
|
Charpy Impact, notched, 23°C
|
3
|
kJ/m2
|
ISO 179/2C
|
|
Charpy 23°C, Unnotch Edgew 80*10*4 sp=62mm
|
14
|
kJ/m2
|
ISO 179/1eU
|
|
Charpy -30°C, Unnotch Edgew 80*10*4 sp=62mm
|
14
|
kJ/m2
|
ISO 179/1eU
|
|
THERMAL
|
Value
|
Unit
|
Standard
|
|
HDT, 1.82 MPa, 3.2mm, unannealed
|
127
|
°C
|
ASTM D 648
|
|
CTE, -40°C to 40°C, flow
|
3.E-05
|
1/°C
|
ISO 11359-2
|
|
CTE, -40°C to 40°C, xflow
|
7.E-05
|
1/°C
|
ISO 11359-2
|
|
Vicat Softening Temp, Rate A/50
|
146
|
°C
|
ISO 306
|
|
Vicat Softening Temp, Rate B/120
|
140
|
°C
|
ISO 306
|
|
HDT/Be, 0.45MPa Edgew 120*10*4 sp=100mm
|
135
|
°C
|
ISO 75/Be
|
|
HDT/Ae, 1.8 MPa Edgew 120*10*4 sp=100mm
|
126
|
°C
|
ISO 75/Ae
|
|
PHYSICAL
|
Value
|
Unit
|
Standard
|
|
Water Absorption, 50% RH, equilib
|
0.06
|
%
|
ASTM D 570
|
|
Mold Shrinkage, flow, 3.2 mm (5)
|
0.2 - 0.4
|
%
|
SABIC Method
|
|
Density
|
1.13
|
g/cm3
|
ISO 1183
|
|
Water Absorption, (23°C/sat)
|
0.2
|
%
|
ISO 62
|
|
Melt Volume Rate, MVR at 280°C/10.0 kg
|
32
|
cm3/10 min
|
ISO 1133
|
|
Source GMD, last updated:2014/12/18
|
|
Parameter
|
|
Injection Molding
|
Value
|
Unit
|
|
Drying Temperature
|
100 - 120
|
°C
|
|
Drying Time
|
2 - 4
|
hrs
|
|
Maximum Moisture Content
|
0.02
|
%
|
|
Melt Temperature
|
280 - 300
|
°C
|
|
Nozzle Temperature
|
280 - 300
|
°C
|
|
Front - Zone 3 Temperature
|
290 - 310
|
°C
|
|
Middle - Zone 2 Temperature
|
270 - 290
|
°C
|
|
Rear - Zone 1 Temperature
|
250 - 270
|
°C
|
|
Hopper Temperature
|
60 - 80
|
°C
|
|
Mold Temperature
|
80 - 120
|
°C
|
|
Source GMD, last updated:2014/12/18
|
|
|
Compare
|
Contact Us
|
|
|
NORYL? Resin
|
|
|
|
Grades
|
Description
|
|
|
731
|
PPE+PS blend. Unfilled. NSF listed for potable water use in several colors (Standard 61). FDA compliant (restrictions apply). UL94 HB rated. Low water absorption. Hydrolytic stability. Dimensional stability. This grade will no longer be
Datasheet
Product Data: Engineering Design Data | Chemical Compatibility
Auto Data: Auto Specification
|
|
|
BN31
|
Blowmoldable. Excellent processability and flammability. Good heat resistance. Low temperature impact strength. Dimensional stability.
Datasheet
Product Data: Engineering Design Data
Auto Data:
|
|
|
EM7430
|
30% glass reinforced, high flow PPO. Automotive. Energy management material.
Datasheet
Product Data: Engineering Design Data
Auto Data:
|
|
|
EN265
|
Extrusion grade. 254F (123C) DTUL. UL94 V-1 rated.
Datasheet
Product Data: Engineering Design Data
Auto Data:
|
|
|
ENG265
|
PPE+PS blend. Unfilled. Suitable for profile extrusion. NSF listed for potable water use in several colors (Standard 61). Low water absorption. Hydrolytic stability. Dimensional stability. Typical applications include tubes for reverse osmo
Datasheet
Product Data:
Auto Data:
|
|
|
EXNL0143
|
PPE+PS, Translucent, extrusion and blow molding.
Datasheet
Product Data:
Auto Data:
|
|
|
EXNL0357
|
PPE+PS, Flame Retardant, UL Grade, Non-Halogen Flame Retaardant, Flame retardant,
Datasheet
Product Data:
Auto Data:
|
|
|
EZ250
|
Automotive wheel covers. Offers superior processability/flow and better chemical resistance when exposed to many automotive fluids over PX0844.
Datasheet
Product Data:
Auto Data:
|
|
|
FE1410PW
|
PPE+PS, 10% Glass Reinforced, Hydrolytic stability, Potable Water Compatible, ISO306 Vicat B/120 of 140C.
Datasheet
Product Data:
Auto Data:
|
|
|
FE1520PW
|
PPE+PS, 20% Glass Reinforced, Hydrolytic stability, Potable Water Compatible, ISO306 Vicat B/120 of 145C.
Datasheet
Product Data:
Auto Data:
|
|
|
FE1630PW
|
PPE+PS, 30% Glass Reinforced, Hydrolytic stability, Potable Water Compatible, ISO306 Vicat B/120 of 158C.
Datasheet
Product Data:
Auto Data:
|
|
|
FE1740PW
|
PPE+PS, 40% Glass Reinforced, Hydrolytic stability, Potable Water Compatible, ISO306 Vicat B/120 of 161C, ISO527 Tensile Modulus of 11300 MPa
Datasheet
Product Data:
Auto Data:
|
|
|
FN215X
|
Structural foam resin. 170F (77C) HDT. Improved reliability and productivity. All values at 20% weight reduction.
Datasheet
Product Data: Engineering Design Data
Auto Data:
|
|
|
FNH2160
|
Structural foam resin. 80C HDT. Improved reliability and productivity. All values at 20% weight reduction.
Datasheet
Product Data:
Auto Data:
|
|
|
FP5140HF
|
PPE+PS, Flame Retardant, PTFE, Flame retardant, Impact Modified,
Datasheet
Product Data:
Auto Data:
|
|
|
FP6130
|
PPE+PS, unfilled, Flame Retardant, non-chlorinated, non-brominated , UL94 V-1 @ 1.5 mm, Vicat ISO 306 B/120 of 114 deg C, GWFI of 960 deg C
Datasheet
Product Data:
Auto Data:
|
|
|
GFN1
|
PPE+PS blend. 10% Glass reinforced. NSF 61 listing in several colors (restrictions apply). FDA compliance (restrictions apply). Low water absorption. Hydrolytic stability. Dimensional stability. Suitable for fluid engineering applications i
Datasheet
Product Data: Engineering Design Data | Chemical Compatibility
Auto Data:
|
|
|
GFN2
|
PPE+PS blend. 20% Glass reinforced. UL746C F1. NSF 61 listing in several colors (restrictions apply). FDA compliance (restrictions apply). Low water absorption. Hydrolytic stability. Dimensional stability. Suitable for fluid engineering app
Datasheet
Product Data: Engineering Design Data | Chemical Compatibility
Auto Data:
|
|
|
GFN3
|
PPE+PS blend. 30% Glass reinforced. NSF 61 listing in several colors (restrictions apply). FDA compliance (restrictions apply). Low water absorption. Hydrolytic stability. Dimensional stability. Suitable for fluid engineering applications i
Datasheet
Product Data: Engineering Design Data | Chemical Compatibility
Auto Data: Auto Specification
|
|
|
HS2000X
|
PPE+PS blend. 17% Mineral reinforced. Non-brominated, non-chlorinated FR system. UL94 V0 and 5VA listing. UL 746C f1. Radiant panel listing. Dielectric strength. Dimensional stability. Suitable for E/E applications.
Datasheet
Product Data: Engineering Design Data | Chemical Compatibility
Auto Data:
|
|
|
IGN320
|
20% glass reinforced PPE + PS. High heat, high modulus automotive applications like ignition coils.
Datasheet
Product Data: Engineering Design Data
Auto Data:
|
|
|
LTA5020
|
PPE+PS, Flame Retardant, UL Grade, Flame retardant, Nonhalogenated,
Datasheet
Product Data:
Auto Data:
|
|
|
N1150
|
NORYL Resin N1150
Datasheet
Product Data:
Auto Data:
|
|
|
NH4050
|
PPE+HIPS, Unfilled, Impact Modifier, Mold Release, Flame Retardant, Mold Release, UL Grade, Non-Chlorinated Non-Brominated Flame Retardant, Impact Modified, High Flow, UL94 V0 at 1.5mm.
Datasheet
Product Data:
Auto Data:
|
|
|
NH5020
|
PPE+PS, Flame Retarded
Datasheet
Product Data:
Auto Data:
|
|
|
NH5120
|
PPE+PS, Flame Retardant, Flame retardant,
Datasheet
Product Data:
Auto Data:
|
|
|
NH7010HF
|
PPE+PS, Flame Retardant, Nonhalogenated,
Datasheet
Product Data:
Auto Data:
|
|
|
PKN4752
|
PPE+PS blend. High Heat. Translucent with yellow tint in natural color. FDA compliant. Extrusion and Injection Molding. Typical applications include High Performance Food Packaging, Electronics and Healthcare Packaging.
Datasheet
Product Data:
Auto Data:
|
|
|
PN275
|
PPE+PS with low mineral loading. High heat, platable applications.
Datasheet
Product Data:
Auto Data:
|
|
|
PN275F
|
PPE+PS with low mineral loading. High heat, platable applications. NSF approved for water contact applications.
Datasheet
Product Data:
Auto Data:
|
|
|
PX0844
|
PPE+PS blend. Unfilled. UL94 HB rated. Low water absorption. Hydrolytic stability. Dimensional stability.
Datasheet
Product Data: Engineering Design Data | Chemical Compatibility
Auto Data: Auto Specification | Color Specification
|
|
|
PX1390
|
Automotive applications, primarily. Excellent electrical properties, easy processability, high heat, 295F (146C) DTUL.
Datasheet
Product Data: Engineering Design Data
Auto Data: Auto Specification
|
|
|
PX4605
|
PPE+PS blend. 20% Glass reinforced. High heat. Dimensional stability. Suitable for automotive and E/E applications.
Datasheet
Product Data: Engineering Design Data
Auto Data:
|
|
|
PX5558
|
30% glass reinforced, high flow PPO.
Datasheet
Product Data:
Auto Data:
|
|
|
RN0401
|
PPE+PS, Flame Retardant, UL Grade,
Datasheet
Product Data:
Auto Data:
|
|
|
SE100HX
|
Improved productivity and reliability. Nonchlorinated, nonbrominated FR.
Datasheet
Product Data:
Auto Data:
|
|
|
SE100X
|
PPE+PS blend. Unfilled. Halogen-Free FR performance. UL94 V0/V1 rated. RTI Elec/Imp/Str 95/80/95. Good flow. Suitable for E/E market indoor/outdoor applications.
Datasheet
Product Data: Engineering Design Data
Auto Data:
|
|
|
SE1GFN1
|
PPE+PS blend. 10% Glass reinforced. Non-brominated, non-chlorinated FR system. UL94 V1 listing. RTI 110/105/110. Dielectric strength. Dimensional stability. Suitable for E/E applications.
Datasheet
Product Data: Engineering Design Data
Auto Data:
|
|
|
SE1GFN2
|
PPE+PS blend. 20% Glass reinforced. Non-brominated, non-chlorinated FR system. UL94 V1 and 5VA listing. RTI 110/105/110. Dielectric strength. Dimensional stability. Suitable for E/E applications.
Datasheet
Product Data: Engineering Design Data | Chemical Compatibility
Auto Data: Auto Specification
|
|
|
SE1GFN3
|
PPE+PS blend. 30% Glass reinforced. Non-brominated, non-chlorinated FR system. UL94 V1 listing. RTI 110/105/110. Dielectric strength. Dimensional stability. Suitable for E/E applications.
Datasheet
Product Data: Engineering Design Data | Chemical Compatibility
Auto Data:
|
|
|
SE1X
|
PPE+PS blend. Unfilled. Non-brominated, non-chlorinated FR system. UL94 V1, UL746C F1. Dielectric strength. Suitable for E/E market indoor/outdoor applications.
Datasheet
Product Data: Engineering Design Data | Chemical Compatibility
Auto Data:
|
|
