美國杜邦 PCT Celanese Thermx CG033 BK010T 30%玻璃纖維增強,黑色.
美國杜邦 PCT Celanese Thermx CG033 NC010 PCT 30%玻璃纖維增強polycyclohexylenedimethylene對二甲酸乙二醇酯樹脂注塑。
美國杜邦 PCT Celanese Thermx CG043 BK010T 40%玻璃纖維增強,黑色.
美國杜邦 PCT Celanese Thermx CG043 NC010 40%玻璃纖維增強,
美國杜邦 PCT Celanese Thermx CG923 BK010 20%玻璃纖維增強,阻燃,黑色
美國杜邦 PCT Celanese Thermx CG923 NC010 20%玻璃纖維增強,阻燃.
美國杜邦 PCT Celanese Thermx CG933 BK010 30%玻璃纖維、阻燃、黑色
美國杜邦 PCT Celanese Thermx CG933 BK010T 30%玻璃纖維、阻燃、
美國杜邦 PCT Celanese Thermx CG943 BK010 40%玻璃纖維增強,阻燃、黑色
美國杜邦 PCT Celanese Thermx CG943 NC010T 40%玻璃纖維增強,
美國杜邦 PCT Celanese Thermx CGT33 BK010T 30%玻璃纖維增強,黑色鋼化,
美國杜邦 PCT Celanese Thermx CGT33 NC010 30%玻璃纖維增強,
美國杜邦 PCT Celanese Thermx TE1001 BK010 40%玻璃纖維增強,黑色
美國杜邦 PCT Celanese Thermx TE3002 BK010 30%玻璃纖維增強,阻燃,黑色的高性能聚酯樹脂注塑。
| elanese Thermx? CG023 NC010 PCT | |||
|---|---|---|---|
| Categories: | Polymer; Thermoplastic; Polyester, TP; Polycyclohexylenedimethylene Terephthalate (PCT); Polycyclohexylenedimethylene Terephthalate (PCT), 20% Glass Reinforced | ||
| Material Notes: |
Thermx? CG023 NC010 is a 20% glass fiber reinforced polycyclohexylenedimethylene terephthalate resin for injection molding.
Celenese acquired the Thermx product line from DuPont in 2010. |
||
| Vendors: |
Celanese Corporation (Ticona) is a solutions-driven company that uses advanced polymer technology to produce high performance plastic materials that are used in a wide spectrum of applications - from children's toys to industrial gears, from tiny optical components to large automotive body parts.
Click here to view all available suppliers for this material. Please click here if you are a supplier and would like information on how to add your listing to this material. |
||
|
|||
| Physical Properties | Metric | English | Comments | ||
|---|---|---|---|---|---|
| Specific Gravity | 1.39 g/cc | 1.39 g/cc | ASTM D 792 | ||
| Density | 1.38 g/cc | 0.0499 lb/in3 | ISO 1183 | ||
| Filler Content | 20 % | 20 % | |||
| Mechanical Properties | Metric | English | Comments | ||
| Hardness, Rockwell M | 72 | 72 | ASTM D 785 | ||
| Tensile Strength at Break | 100 MPa | 14500 psi | ISO 527 | ||
| Tensile Strength, Ultimate |
100 MPa @Temperature 23.0 °C |
14500 psi @Temperature 73.4 °F |
ASTM D 638 | ||
| Elongation at Break | 2.3 % | 2.3 % | ISO 527 | ||
|
2.7 % @Temperature 23.0 °C |
2.7 % @Temperature 73.4 °F |
ASTM D 638 | ||
| Tensile Modulus |
6.40 GPa @Temperature 23.0 °C |
928 ksi @Temperature 73.4 °F |
ISO 527 | ||
| Flexural Strength | 155 MPa | 22500 psi | ASTM D 790 | ||
| 155 MPa | 22500 psi | ISO 178 | |||
| Flexural Modulus | 5.80 GPa | 841 ksi | ISO 178 | ||
| 5.90 GPa | 856 ksi | ASTM D 790 | |||
| Izod Impact, Notched |
0.600 J/cm @Temperature 23.0 °C |
1.12 ft-lb/in @Temperature 73.4 °F |
ASTM D 256 | ||
| Izod Impact, Unnotched |
5.20 J/cm @Temperature 23.0 °C |
9.74 ft-lb/in @Temperature 73.4 °F |
ASTM D 4812 | ||
| Izod Impact, Notched (ISO) |
6.00 kJ/m2 @Temperature 23.0 °C |
2.86 ft-lb/in2 @Temperature 73.4 °F |
ISO 180/1A | ||
| Charpy Impact Unnotched |
3.50 J/cm2 @Temperature 23.0 °C |
16.7 ft-lb/in2 @Temperature 73.4 °F |
ISO 179/1eU | ||
| Charpy Impact, Notched |
0.600 J/cm2 @Temperature 23.0 °C |
2.86 ft-lb/in2 @Temperature 73.4 °F |
ISO 179/1eA | ||
| Electrical Properties | Metric | English | Comments | ||
| Volume Resistivity | 1.00e+15 ohm-cm | 1.00e+15 ohm-cm | ASTM D 257 | ||
| Surface Resistance | 1.00e+17 ohm | 1.00e+17 ohm | ASTM D 257 | ||
|
Dielectric Constant
|
3.1 @Frequency 1000 Hz, Temperature 23.0 °C |
3.1 @Frequency 1000 Hz, Temperature 73.4 °F |
ASTM D 150 | ||
|
3.1 @Frequency 100000 Hz, Temperature 23.0 °C |
3.1 @Frequency 100000 Hz, Temperature 73.4 °F |
ASTM D 150 | |||
|
3.1 @Frequency 1.00e+6 Hz, Temperature 23.0 °C |
3.1 @Frequency 1.00e+6 Hz, Temperature 73.4 °F |
ASTM D 150 | |||
| Dielectric Strength |
19.7 kV/mm @Thickness 3.20 mm, Temperature 23.0 °C |
500 kV/in @Thickness 0.126 in, Temperature 73.4 °F |
500 V/s, Short Time; ASTM D149 | ||
|
Dissipation Factor
|
0.0030 @Frequency 1000 Hz |
0.0030 @Frequency 1000 Hz |
ASTM D 150 | ||
|
0.011 @Frequency 100000 Hz |
0.011 @Frequency 100000 Hz |
ASTM D 150 | |||
|
0.011 @Frequency 1.00e+6 Hz |
0.011 @Frequency 1.00e+6 Hz |
ASTM D 150 | |||
| Thermal Properties | Metric | English | Comments | ||
| Melting Point | 285 °C | 545 °F | 10°C/min; ISO 11357-1/-3 | ||
| Deflection Temperature at 1.8 MPa (264 psi) | 250 °C | 482 °F | ISO 75-1/-2 | ||
| 256 °C | 493 °F | ASTM D 648 | |||
| Processing Properties | Metric | English | Comments | ||
| Melt Temperature | 300 °C | 572 °F | Optimum | ||
| 295 - 310 °C | 563 - 590 °F | ||||
| Mold Temperature | 100 °C | 212 °F | Optimum | ||
| 80.0 - 120 °C | 176 - 248 °F | ||||
| Drying Temperature | 95.0 °C | 203 °F | |||
| Dry Time | 4 - 6 hour | 4 - 6 hour | Dehumidified Dryer | ||
| Moisture Content | <= 0.030 % | <= 0.030 % | |||
|
De |
|||||
| Color | Natural | ||||
| Drying Recommended | Yes | ||||
| Features | Electrical Properties, Good | ||||
| Filler | Glass fiber reinforcement | ||||
| Forms | Pellets | ||||
| Generic | PCT | ||||
| Part Marking Code | >PCT-GF20< | ISO 11469 | |||
| Polymer Family | Polyester | ||||
| Polymer Type | PCT | ||||
| Processing Method | Injection Molding | ||||
| Product Category | Electrical Resins | ||||
| Glass Reinforced Resins | |||||
| Region Available | Americas | ||||
| Asia/Pacific | |||||
| Europe | |||||
| Resin Identification | PCT-GF20 | ISO 1043 | |||
| Uses | Connectors | ||||
| E/E Applications | |||||
