性能特點： ? 料斗和底座可任意方向調節 ? 采用磁簧開關,感應靈敏,質量穩定 ? 采用感應式高壓風機,體積小、噪音小、壽命長 ? 逆轉除塵裝置（可選） Features: ? Hopper and base adjustable. ? Magnetic reed switch adopted. ? Induction high-pressure motor adopted, small footprint, low noise and durable. ? Pump reverse system available. 技術參數： 型號Model VAL-300G VAL-400G 馬達 Motor 型式 Type 碳刷式 Carbon brush 感應式induction 規格 Specification 1KW/1.3HP 1φ 0.75KW/1HP 3φ 輸送能力（kg/h) conveying capacity 300 400 吸料揚程 Loading distance 3.5 4 靜風壓(mm/H2O) Static wind pressure 1300 1400 儲料桶容量(L) Reservoir volume 6 10 送料管內徑Conveying tube inner dim. f38 f38 配送料管 Specification of the attached hoses f38mm×3.5m 1pcs f38mm×4m 1pcs 外形尺寸 Dimensions LxWxH 　38x28x58 54×43×74 凈重 Net weight 12 28 ? 參數中的輸送能力及吸料揚程是以ABS原料為測試材料得出的數據，實際參數根據塑料比重、形狀及輸送長度、高度、管路特性、參數設定等因素而改變。 ? 吸料機在輸送材料時，料管需選配耐160度高溫料管。 ? The parameters of the conveying capacity and suction lift are educed from tests on ABS. The actual parameters may be different due to the differences of the specific gravity and the shape of the material, the conveying distance and height, the specialty of pipeline and the setting of parameters. ? Heat-resistant(160℃) pipes should be used when conveying hot material.
