點擊圖片查看大圖|
序號 |
名稱 Name |
數據 |
說明 |
|
|
Number |
Date |
Remark |
||
|
|
||||
|
1 |
制品容量 Product volume(L) |
6L |
|
|
|
|
|
|
|
|
|
2 |
合模次數 Clamping times |
60-300 次 /hr |
|
|
|
|
|
|
|
|
|
3 |
螺桿直徑 Diameter of screw |
Φ65 |
38CrMoALA |
|
|
|
|
|
|
|
|
4 |
螺桿長徑比 Screw (L/D)ratio |
25/1 |
|
|
|
|
|
|
|
|
|
5 |
塑化能力 Plasticizing capacity |
60-90kg |
|
|
|
|
|
|
|
|
|
6 |
驅動功率 Driving power |
11kw |
變頻 |
|
|
|
|
|
|
|
|
7 |
溫控段數 Heating segments |
4 |
|
|
|
|
|
|
|
|
|
8 |
加溫功率 Heating power |
16kw |
|
|
|
|
|
|
|
|
|
9 |
升降范圍 Lift range |
0-150mm |
|
|
|
|
|
|
|
|
|
10 |
鎖模力 Clamping force |
78kn |
|
|
|
|
|
|
|
|
|
11 |
模板間距 Platen opening stroke |
150-550mm |
|
|
|
|
|
|
|
|
|
12 |
模板安裝尺寸 Mold size |
350×460mm |
|
|
|
|
|
|
|
|
|
13 |
模板參考厚度 Mold thickness |
155-300mm |
|
|
|
|
|
|
|
|
|
14 |
大口模直徑 Max diameter of die head |
150mm |
|
|
|
|
|
|
|
|
|
15 |
加熱參考功率 Heating power |
6kw |
|
|
|
|
|
|
|
|
|
16 |
溫控段數 Heating segments |
3 |
|
|
|
|
|
|
|
|
|
17 |
總裝機參考功率 Total power |
40kw |
|
|
|
|
|
|
|
|
|
18 |
平均能耗 Average energy consume |
28kw |
|
|
|
|
|
|
|
|
|
19 |
耗氣量 Air consume |
1m³/min |
|
|
|
|
|
|
|
|
|
20 |
外形尺寸（長 × 寬 × 高 Dimension |
4000×2300×2800mm |
|
|
|
(LxWxH) |
|
|||
|
|
|
|
||
|
21 |
機組總重量 Weight |
6.5T |
|
洗衣液桶吹瓶機設備洗衣液桶吹瓶機設備洗衣液桶吹瓶機批發洗衣液
